D Series Bench Drills

D13 Bench Drill
D13R Bench Drill
D19 Bench Drill
D16 Bench Drill
D Series Bench Drill Button

D Series Bench Drills

From £131.00 inc. VAT

Our Bench Drills are ideal for the hobby engineer. High quality, robust drilling machines with table elevation.

Stock Code: N/A Category:

Description

Our range of D Series Bench Drills are ideal for use in your hobby workshop. Robust heavy duty drills with a cast iron base making them easy to use and set up. High performance, versatile drills suitable for a variety of drilling applications.

Available in a range of types and styles to suit your needs. Featuring keyless chuck and table elevation with additional features dependent on model type.

Comes complete with everything you need to get started including drill chuck and guard. Additional tools and accessories are also available including drill chuck arbors and key type drill chucks.

Download Manual Button

D13 D13R D16 D19
Throat 104mm 125mm 165mm 178mm
Drilling Capacity 13mm 13mm 16mm 20mm
Chuck Size 1-13mm 1-13mm 3-16mm 3-16mm
Spindle Travel 50mm 60mm 80mm 80mm
Spindle to Base 350mm 535mm 620mm 600mm
Spindle to Table 210mm 415mm 450mm 410mm
Table Size 165x160mm 190x195mm Ø300mm 290x290mm
Spindle Taper B16 MT2 MT2 MT2
Height 585mm 800mm 990mm 1000mm
Net Weight 20kg 37kg 42kg 86kg
Column Diameter 48mm 60mm 70mm 80mm
Height 585mm 800mm 990mm 1000m
Base Size 280 x 175mm 200 x 300mm 230 x 400mm 430 x 270mm
Motor 0.25kW 0.37kW 0.55kW 0.65kW

Features

  • Cast iron column
  • Rigid construction
  • Ergonomic hand wheels



Standard Accessories

  • Drill chuck
  • Chuck guard
  • NVR switch gear
