Champion 30VS Mill

Champion 30VS mill with DRO
Champion 30VS mill with tilting head

Champion 30VS Mill

£2,350.00 inc. VAT

Our Champion 30VS Mill is a high precision, quality machine. Featuring digital speed and depth readouts, and variable speed.

Call us today on 01244 531631 to place a 10% deposit to secure yours today.

New stock on the way.

Email when stock available

Stock Code: MIL-CHAMP-30-M Category:

Description

The ideal hobby milling machine, our Champion 30VS model benefits from variable speed and digital read out with column guideway. A quality machine with high levels of precision making it an ideal addition to your home workshop.

Capable of performing a variety of milling functions, achieving spindle speeds up to 3000rpm with MT3 spindle taper. Comes complete with accessories including drill chuck and arbor and milling drawbar.

Additional tools and accessories are available for this machine including collet chucks and clamping kits.

Comes complete with stand and tray.

Now with 3 Axis DRO.

Download Manual Button

Drilling Capacity30mm
End Milling Capacity25mm
Face Milling Capacity75mm
Table Size840x210mm
Longitudinal Travel (X)
540mm
Cross Travel (Y)220mm
Vertical Travel (Z)340mm
Distance Spindle-Cross Table470mm
T-slot Size14mm
Spindle Bore TaperMT3/M12
Sleeve Travel70mm
Range of Spindle Speeds50-2250rpm
Headstock Tilt Left & Right±90°
Motor Power1.1Kw (1.47hp)
Dimensions (LxWxH)1050x730x1180mm
Net Weight220kg

Features

  • Dovetail column
  • Variable speed
  • Tilting head
  • Digital quill depth read-out
  • Column guideway covers
  • Digital depth read-out
  • Digital speed display



Standard accessories

  • 1-13mm drill chuck and arbor
  • Milling drawbar
