3 Jaw Self-centring Mono Block Chucks
£81.99 – £200.99 inc. VAT
Self centring jaw chuck for metal turning.
Description
These 3 jaw self centring chucks are ideal for holding workpieces and lathe tools. Featuring fully ground mono-block jaws allowing for precision.
Available in a range sizes from 80mm – 200mm with a plainback fitting.
Clamping Range
| Clamping Range | |||||||
|---|---|---|---|---|---|---|---|
| Size | Internal Jaw (A-A1) | Internal Jaw (B-B1) | External Jaw (C-C1) | ||||
| 80mm | 2-22mm | 25-70mm | 22-63mm | ||||
| 100mm | 2-30mm | 30-90mm | 30-80mm | ||||
| 125mm | 2.5-40mm | 40-125mm | 40-110mm | ||||
| 160mm | 3-55mm | 50-160mm | 55-145mm | ||||
| 200mm | 4-85mm | 65-200mm | 65-200mm | ||||
| Installation Dimensions | |||||||
| Size | D1 | D2 | D3 | H1 | h | Z-d | H |
| 80mm | 55mm | 66mm | 16mm | 50mm | 4mm | 3mm M6 | 66.5mm |
| 100mm | 72mm | 84mm | 22mm | 55mm | 3mm | 3mm M8 | 74.5mm |
| 125mm | 95mm | 108mm | 30mm | 58mm | 4mm | 3mm M8 | 84.5mm |
| 160mm | 130mm | 142mm | 45mm | 65mm | 5mm | 3mm M8 | 94mm |
| 200mm | 165mm | 180mm | 65mm | 75mm | 6mm | 3mm M10 | 109mm |
Installation Dimensions
